Tech specs
System
Processor: STM32WB55RG, ARM Cortex-M4
Bluetooth Low Energy 5.4
Battery: 2100 mAh (up to 28 days)
Display: LCD Monochrome 128x64 px
MicroSD: up to 256 GB (SPI mode)
NFC
Read NFC cards
Save to SD card
Write (only rewritable cards)
Emulate:
- NXP MIFARE Classic®, Ultralight®, DESFire®, etc.
- FeliCa™
- HID iClass (PicoPass™)
- NFC Forum protocols
Sub-1 GHz module
Supported frequencies: 315-900 MHz
Read & decode signals
Save to SD Card
Analyze unknown signals (Read RAW)
Generate new remotes
Infrared
Read infrared signals
Save to SD card
Emulate infrared signals
Built-in signal library
Guess signals for TV and AC
Supported protocols:
- NEC family
- Kaseikyo
- RCA
- RC5, RC6
- Samsung
- SIRC
RFID
Frequency: 125 kHz
Modulation: AM/OOK
Coding: AKS, PSK
Supported cards:
- EM400x, EM410x, EM420x
- HID
- Indala
- FDX (A & B)
- Pyramid
- AWID
- Viking
- Jablotron
- Paradox
- PAC Stanley
- Keri
- Gallagher
- NexWatch
iButton 1-Wire
Read 1-Wire keys
Save to SD Card
Write (only rewritable keys)
Emulate 1-Wire keys
Supported protocols:
- Dallas DS199x, DS1971
- CYFRAL
- Metakom
- TM2004
- RW1990
